Fume Hood, CA-FMH-DF Series
- Maximum Opening: 520mm
- Work Surface Height: 750mm
- Airflow Velocity: Adjustable, 0.3~0.8 m/s
- Filter: Active Carbon Filter
- Control System: Microprocessor controller with LCD display
Description
FMH series fume hood is a kind of negative pressure ventilation system for protecting operator and laboratory, utilizes carbon filtration to protect laboratory personnel from toxic chemical fumes, odors, and particles. Known for its plug-and-play feature and mobility, fume hood guarantees a hassle-free installation and no lab work interruption.
Humanized Features：
- Ergonomic Control Panel Location, centered and angled down for an easy reach & viewing.
- Made of solid psychological board, resistant to strong acid and alkali
- The non-direct light source design can effectively relieve the operator’s visual fatigue under the condition of ensuring the illumination
- Intuitive and easy-to-use microprocessor controller with LCD display, graphical and digital display of the operating status of each function, such as filter life, UV life etc.
Safety Features:
- Front sliding sash interlock with fan and UV lamp
- UV sterilization with UV lamp timing function
- Front sash and side windows are made of UV-resistant tempered glass
- The host and sockets have independent capacitors to prevent current overload
Convenience Features：
- Memory function in case of power-failure.
- Filter and UV life indicators facilitate a timely replacement plan
- Two side glass windows installed for easy experiment observation
- Equipped with temperature sensor to show the real temperature during operation
- Waterproof socket provide convenience for small instruments to be used in the operating area
Specifications
| Model | CA-FMH-D3F | CA-FMH-D4F | CA-FMH-D5F | CA-FMH-D6F | |
| External Dimensions
(W*D*H)(mm) |
1000*850*2150 | 1220*850*2150 | 1525*850*2150 | 1830*850*2150 | |
| Internal Dimensions
(W*D*H)(mm) |
880*730*745 | 1100*730*745 | 1405*730*745 | 1710*730*745 | |
| Control System | Microprocessor controller with LCD display, graphical and digital display of the operating status of each function. | ||||
| Maximum Opening | 520mm | ||||
| Work Surface Height | 750mm | ||||
| Airflow Velocity | Adjustable, 0.3~0.8 m/s | ||||
| Air Volume(m³/hr)/(cfm) | 657/387 | 868/511 | 1085/639 | 1085/639 | |
| Active Carbon Filter | Dimensions(W*D*H)(mm) | 750*495*30 | 1055*495*30 | 1360*495*30 | 1665*495*30 |
| Quantity | 1pc | ||||
| Sound Emission | ≤68dB(A) | ||||
| Lighting Lamp | 6.5W*1 | 9.6W*1 | 9.6W*1 | 9.6W*1 | |
| LED type, Intensity ≥900Lx | |||||
| UV Lamp | 20W*1 | 30W*1 | 30W*1 | 30W*1 | |
| With timing function, Interlock with front sliding sash. Emission of 253.7 nanometers for best sterilization effect. | |||||
| Power Consumption | 400W | 500W | 500W | 500W | |
| The power consumption does not include external device connected via power socket | |||||
| Cabinet Construction | Main Body: Electro-galvanized steel with antimicrobial powder coating | ||||
| Work Table: Solid physicochemical board, resistant to strong acid and alkali | |||||
| Manual Sliding Sash: 5 mm UV resistant tempered glass with counter-balance system and ergonomic handle | |||||
| Side Windows: 5 mm UV resistant tempered glass | |||||
| Electricity | AC220V ±10%, 50/60Hz,1P | ||||
| Standard Accessories | Base stand*1;
LED lamp*1; UV lamp*1; Waterproof socket*2(only 1 for FMH-D3F); Casters with brakes*4; Activated carbon filter*1; Water tap*1; Gas tap*1; Water sink(220*95*150mm)*1; Exhaust duct-10meters*1; Solid physicochemical countertop*1 |
||||
| Optional Accessories | HEPA filter; Wind speed sensor; Foma casters; 304 stainless steel countertop; Base Cabinet | ||||
| Shipping Weight（kg） | 250 | 280 | 330 | 390 | |
| Shipping Dimensions
（W*D*H）(mm) |
1170*1130*1660 | 1360*1100*1635 | 1665*1100*1635 | 1970*1100*1635 | |
| Shipping Volume (m3) | 2.2 | 2.5 | 3.1 | 3.6 | |
