| Model |
MSC-ST7045 |
| Optics |
Finite Distance Optical System |
| Magnification |
Zoom objective 6.7X-45X |
| Observation Tubes |
Interpupillary distance adjustment:54-75mm；Diopter adjustment:±5 diopters |
| Viewing Head |
Binocular head, inclined at 45° |
| Optical Coating |
Transmittance ≥ 95% |
| Eyepiece |
WF10X/22mm high-eyepoint, wide-field; Convenient for observers wearing glasses |
| *Optional eyepiece15X/16mm，20X/12mm，25X/9mm，30X/8mm |
| Objective |
0.67X-4.5X stereo zoom; Zoom ratio:6.7:1 |
| *Aux lens：0.5X，2X |
| Focusing |
Focusing track mount with vertical working distance 104mm |
| Stand |
Track stand |
| Vertical height：300mm；Mounting size：φ76mm；Focusing distance：106mm； |
| With φ95mm B/W plastic & Perspex plate and paired clips；Base size：205×275×40mm |
| Illumination |
Top and bottom LED illumination with an independent control；Input power：110v~240v |
| C-Mount |
MSC 1X C-Mount；*MSC 0.5X C-Mount； |
| Electricity |
100-240V AC,50/60Hz |
| Package Dimension (W*D*H) (mm) |
530*330*420 |
| Gross Weight (Kg) |
9 |
| *Optional |
3.35X-270X with optional eyepieces and objectives |
| Notes: 3.5X-270X with optional eyepieces and objectives |
| *Optional Configuration |
