Description
It’s a professional localized air purification equipment suitable for pharmaceuticals, medical and health, scientific research laboratories of universities and colleges,photoelectric/microelectronics manufacturing and other fields.
High efficiency filter is adopted to ensure air cleanliness
- Adopting moisture-proof and flame retardant glass fiber high efficiency filter (HEPA), the interception efficiency of solid particles larger than 0.3 micron diameter is greater than 99.99% .
- The cleanliness is better than the 100 cleanliness requirements, practical and safety.
Split underframe makes it easier to move
- The base box is detachable, which is flexible to carry and easy to install.
Anti-radiation tempered glass is more safer
- Adopt transparent anti-radiation tempered glass to increase daylight and keep away from ultraviolet radiation.
Sterilization intelligent interlock, automatic control
- The illuminating lamp and the UV lamp are interlocked, and the UV lamp can only be turned on when the illuminating lamp is turned off; after the fluorescent lamp is turned on, the UV lamp will be turned off immediately to ensure practical safety.
- The UV lamp has the function of timing off, and the sterilization time is adjustable within a certain range.
304 stainless steel table top
- The front arc convex design prevents liquid from flowing out and is more safer
Display panel
- Intelligent control, easy to operate
Waterproof socket:
- prevent liquid from entering the socket, and use electricity safely
UV lamp
- one button UV lamp sterilization, intelligent interlock to prevent radiation to people
Specifications
Mode | CA-LCB-VA1300 | |
Flow Type | Vertical | |
Voltage/Frequency(V/Hz) | AC 220/50 | |
Power(W) | 1200 | |
Vibration Amplitude(UM) | 2 | |
Exhaust Filter Typical Efficiency | H13 HEPA,99.99%@0.3um | |
Average Velocity (m/s) | 0.2-0.5 | |
Fluorescent Lamp Intensity(Lux) | ≥300 | |
Net/Gross Weight (approx.) | kg | 150/178 |
lbs | 330/392 | |
Sound Emission dB(A) | 62 | |
Internal | mm | 1300*516*520 |
Dimensions(W*D*H) | in | 51.2*20.3*20.5 |
External Dimensions(W*D*H) | mm | 1370*611*1754 |
in | 53.9*24.1*69.1 | |
Packing Dimensions(W*D*H) | mm | 1550*820*1200 |
in | 59.3*29.3*50.4 | |
Cleanliness Classification | ISO 14644.1 Class 5 | |
Container Load (20’/40’/40’H) | 10/25/25 |
