Applications
- Sterile filtering protein solution
- Tissue culture media filtration
- Tissue culture additive filtration
Technical Specifications
| Parameters | 13mm | 25mm | 30mm | |||
| Membrane Material | PES | PES | PES | |||
| Housing Material | PP | PP | PP | |||
| Filter Diameter (mm) | 13mm | 25mm | 30mm | |||
| Filtration Area (cm2 ) | 1.09 | 4.08 | 4.9 | |||
| Pore Size(μm) | 0.22 | 0.45 | 0.22 | 0.45 | 0.22 | 0.45 |
| Holdup Volume (μl) | <20 | <100 | <100 | |||
| Sample Volume (ml) | <10 | <100 | <120 | |||
| Maximum Operating Temperature | 90°C | 90°C | 90°C | |||
| Maximum Operating Pressure (psi) | 87 | 87 | 87 | |||
| Applicable pH Value | 1-14 | 1-14 | 1-14 | |||
| Available Sizes |
| Pore Size:0.22μm, Diameter:4mm |
| Pore Size:0.45μm, Diameter:4mm |
| Pore Size:0.1μm, Diameter:13mm |
| Pore Size:0.1μm, Diameter:13mm |
| Pore Size:0.22μm, Diameter:13mm |
| Pore Size:0.22μm, Diameter:13mm |
| Pore Size:0.22μm, Diameter:13mm |
| Pore Size:0.45μm, Diameter:13mm |
| Pore Size:0.45μm, Diameter:13mm |
| Pore Size:0.45μm, Diameter:13mm |
| Pore Size:0.1μm, Diameter:25mm |
| Pore Size:0.10μm, Diameter:25mm |
| Pore Size:0.22μm, Diameter:25mm |
| Pore Size:0.22μm, Diameter:25mm |
| Pore Size:0.22μm, Diameter:25mm |
| Pore Size:0.22μm, Diameter:25mm |
