Description
- Streamlined housing facilitates the cleaning process without opening the housing. Also, you can put some consumables
- Uses imported cross-roller guide rails and a screw motion mechanism to ensure precision
- Advanced high-precision micro-drive feed system
- Hand-wheel can be locked at any position
- Cassette holder can be locked at any position along each of the three axes
- The precise positioning system provides accurate X- and Y- axis adjustment
- Easy and fast switching between two specimen clamps (paraffin block clamp and cassette clamp);
- The red bar on the blade holder covers the whole length of blade
- The blade holder can be laterally moved and adjusted, without manually move the blade, enabling use of the full length of the blade (slicing at three different segments);
- Hand-wheel balance is precisely adjusted and can be locked at any position
- Magnetically fixed large waste tray is easy to install and uninstall
Specifications
| RMT-M260 | |||
| Section Thickness Setting Range | 0–60μm | Movement Range of the Base of Blade Holder Base | 0-60mm (front to back) |
| Section thickness setting options | 2–10μm increment 1μm | Movement Range of the Blade Press plate | 0-23mm |
| 10–20μm increment 2μm | Specimen Holder Rotation | at any angle within360 degrees | |
| 20–60μm increment 5μm | Maximum Specimen Size | Standard wax block clip 39mm×40mm （Other sizes available） | |
| Trimming Thickness Setting Range | 0- 60μm | Specimen Orientation | XY – 8° |
| Minimum Setting of Sectioning Thickness | 1μm | Precision Error | ±1％ |
| Total Horizontal Specimen Feed | 29mm | Dimensions | 610×530×420mm(L*W*H) |
| Vertical Specimen Stroke | 60mm | Weight | 40kg |
