Description
It is suitable for experiments in biopharmaceuticals, pharmaceuticals, cell biology and other fields, for the isolation and purification of microbial organisms, cellular proteins, mycobacteria and immune.
Advantages
1. Display: 5-inch high-definition touch screen, simple operation, intuitive display;
2. Security: Automatic identification of 9 different rotors, eliminate the user misuse of security risks (Optional function);
3. Control: It has 9 files of acceleration and 10 files of deceleration level, which can effectively prevent secondary suspension and have a good centrifugal effect；
4. Program: 15 groups of programs can be stored for users to use;
5. Performance: AC frequency conversion motor, high precision speed control;
6. Safety: There are various protections such as Overspeed, door protection, imbalance protection, etc. to ensure the safety of human and machine;
7. Convenience: Free switching of speed and RCF;
8. Particularity: Special air duct to ensure the rotor works under normal temperature;
9. Speciality : Airtight rotor, effectively prevent aerosols.
Specifications
| Model | CA-CFGR-B21B |
| Max. Speed | 21000r/min |
| Max. RCF | 29828×g |
| Max.Capacity | 4×750ml |
| Speed Accuracy | ±30r/min |
| Time Setting | 1min～99 min59sec，Continuous centrifuge : Hold |
| Temperature Control Range | -20℃～40℃ |
| Temperature Control Accuracy | ±1℃ |
| Compressor | Imported high-performance compressor unit, CFC-free refrigerant |
| Power Supply | AC220±22V,50/60Hz,16A or AC110±20V,50/60Hz,32A |
| Noise | ≤60dB(A) |
| Dimensions(L*W*H) | 720×743×410mm |
| Net Weight | 110Kg |
| Package Dimension (W*D*H)(mm) | 960*810*590 |
Rotor (optional)
| Rotor Type | Max Speed(rpm) | Max RCF(×g) | Max Capacity | Tube Size(mm) |
| Angle Rotor | 21000 | 26750 | 18×0.5ml | Φ8×32 |
| Angle Rotor | 21000 | 29828 | 12×1.5/2ml | Φ10×42 |
| Angle Rotor | 16500 | 24890 | 24×1.5/2ml | Φ10×42 |
| Angle Rotor | 15000 | 25650 | 32×1.5/2ml | Φ10×42 |
| Angle Rotor | 15000 | 24270 | 48×1.5/2ml | Φ10×42 |
| Angle Rotor | 16500 | 19170 | 12×5ml | Φ13×53 |
| Angle Rotor | 15000 | 23120 | 12×10ml | Φ16×83 |
| Angle Rotor | 15000 | 23640 | 8×15ml | Φ17×121 |
| Angle Rotor | 14000 | 22022 | 12×15ml | Φ17×121 |
| Angle Rotor | 15000 | 23640 | 6×50ml | Φ29×120 |
| Angle Rotor | 12000 | 15610 | 8×50ml | Φ29×120 |
| Angle Rotor | 12000 | 15465 | 4×100ml | Φ37.9×119 |
| Angle Rotor | 10000 | 11808 | 6×100ml | Φ37.9×119 |
| Swing Rotor | 4200 | 3500 | 4×250ml | Φ29×120 |
| Swing Rotor | 4000 | 3040 | 4×500ml | Φ80×137 |
| Swing Rotor | 4000 | 2810 | 4x8x15ml | Φ17×121 |
| Swing Rotor | 4000 | 2810 | 4×100ml | Φ37.9×119 |
| Swing Rotor | 4000 | 3180 | 4×750ml | Φ99×137 |
| Swing Rotor(microplate) | 4000 | 2300 | 2×2×96well |
