| ECG |
Lead Mode: 5 Leads ( R, L, F, N, C or RA, LA, LL, RL,V) |
| Lead selection: I, II, III, avR, avL, avF, V, |
| Waveform: 2 ch |
| Lead mode: 3 Leads ( R, L, F or RA, LA, LL) |
| Lead selection: I, II, III, |
| Waveform: 1 ch |
| Gain: ′2.5mm/mV, ′5.0mm/mV, ′10mm/mV, ′20mm/mV, auto |
| HR and Alarm |
| Range Adult: 15 ~ 300 bpm |
| Neo/Ped: 15 ~ 350 bpm |
| Accuracy : ± 1% or ± 1bpm,which great |
| Resolution: 1 bpm |
| Sensitivity: > 200 (uV P-P) |
| Differential Input Impedance: > 5 MΩ |
| CMRR |
Monitor: > 105 dB |
| Operation: > 105 dB |
| Diagnosis: > 85 dB |
| Electrode offset potential: ±300mV |
| Leakage Current: < 10 uA |
| Baseline Recovery: < 3 S After Defi. |
| ECG Signal Range: ±8 m V ( Vp-p ) |
| Bandwidth |
| Surgery: 1 ~ 15 Hz |
| Monitor: 0.5 ~ 35 Hz |
| Diagnostic: 0.05 ~ 100 Hz |
| Calibration Signal: 1 (mV p-p), Accuracy:±5% |
| ST Segment Monitoring Range: Measure and Alarm -2.0 ~ +2.0 mV |
| ARR Detecting |
| Type: ASYSTOLE, VFIB/VTAC, COUPLET, BIGEMINY, TRIGEMINY, R ON T, VT>2, PVC, |
| TACHY, BRADY, MISSED BEATS, PNP, PNC |
| Alarm: Available |
| Review: Available |
| RESP |
Method: Impedance between R-F(RA-LL) |
| Differential Input Impedance: >2.5 MΩ |
| Measuring Impedance Range: 0.3~5.0Ω |
| Base line Impedance Range: 0 – 2.5 KΩ |
| Bandwidth: 0.3 ~ 2.5 Hz |
| Resp. Rate |
Measuring and Alarm Range |
| Adult: 0 ~ 120 rpm |
| Neo/Ped: 0 ~ 150 rpm |
| Resolution: 1 rpm |
| Accuracy : ±2 rpm |
| Apean Alarm: 10 ~ 40 S |
| NIBP |
Method: Oscillometric |
| Mode: Manual, Auto, STAT |
| Measuring Interval in AUTO Mode: 1, 2, 3, 4, 5, 10, 15, 30, 60, 90, 120, 180, 240,480 (Min) |
