Description
Fast, efficient sample concentration suitable for a variety of tube controlled by PID with high precision temperature. The gas delivery needles are independent, which could control gas separately to ensure sample concentration a good uniformity of sample concentration. The height of the sample concentrator’s gas reservoir is located on an adjustable stand for accurate height control. This flexible combination of blocks makes the instrument compatible with most sample vessels.
Features:
- Independent needles avoid cross-contamination.
- Every gas volume is adjustable.
- Needles can work combined or alone.
- Convenient to adjust the gas for samples.
- Accurate temperature, large temperature range, and easy to calibrate.
- Safe to use due to the height-adjustable stand.
- Stand rod with scale for accurate height control.
Specifications
| Model | CA-NEC150-1 | CA-NEC150-2 |
| Block Quantity | 1 | 2 |
| Nitrogen Flow | 0~12L/min | |
| Temperature Control Range | RT. +5℃ ~150℃ | |
| Heating Up Rate | ≤ 30min (20℃~150℃ ) | |
| Temperature Stability @40℃ | ±0.3℃ | |
| Temperature Stability @100℃ | ±0.5℃ | |
| Temperature Stability @120℃ | ±1℃ | |
| Timer | 0~99h59min | |
| Pressure | ≤ 0.2MPa | |
| Power | 200W | 400W |
| Dimension(W*D*H) | 220*290*540mm | |
| N.W./G.W. | 3.9kg/8.2kg | 5kg/11kg |
| Shipping Dimension(L*W*H) | 570*410*310mm | |
Optional blocks
| Type | Picture | Tube Diameter | Capacity | Dimension |
| D1A |  |
6mm | 12 | 96.5*76.5*50mm
|
| D2A |  |
7mm | 12 | 96.5*76.5*50mm |
| D3A |  |
10mm | 12 | 96.5*76.5*50mm |
| D4A |  |
12mm | 12 | 96.5*76.5*50mm |
| D5A |  |
13mm | 12 | 96.5*76.5*50mm |
| D6 |  |
15mm | 12 | 96.5*76.5*50mm |
| D7 |  |
16mm | 12 | 96.5*76.5*50mm |
| D8 |  |
19mm | 12 | 96.5*76.5*50mm |
| D9 |  |
20mm | 12 | 96.5*76.5*50mm |
| D10 |  |
26mm | 8 | 96.5*76.5*50mm |
| D11 |  |
28 mm | 6 | 96.5*76.5*50mm |
| D12 |  |
38mm | 3 | 96.5*76.5*50mm |
| D13A |  |
0.2mL centrifuge tube | 12 | 96.5*76.5*50mm |
| D14A |  |
0.5mL centrifuge tube | 12 | 96.5*76.5*50mm |
| D15A |  |
1.5mL centrifuge tube | 12 | 96.5*76.5*50mm |
| D16A |  |
2mL centrifuge tube | 12 | 96.5*76.5*50mm |
| Gas flow controller for option |  |
