Description
It has been widely used in food, textile, geology, metallurgy, plastics, coal, cosmetics, petrochemicals, biomedicine, environmental monitoring, sewage treatment, and other fields.
Features
- Special-designed sample digestion vessel
The automatic vent and self-resealing structure ensure the digestion vessels can automatically release pressure and instantly reseal when a sudden over-pressure situation occurs.
- Contact-lesstemperature and pressure monitoring system
The advanced contactless IR sensor could measure the real-time temperature of sample solutions in each digestion vessel. Meanwhile, the contact-less pressure sensor could monitor the real-time pressure of each vessel.
- Large storage capacity
It can edit and store 255 types of programs according to the user’s requirements, and each method program can set parameters (temperature, pressure, time, microwave power) according to their own requirements, which provides convenient operation for users.
- Safety protection system
With a high-strength double-locked security door, real-time temperature and pressure monitoring, automatic adjustment of over-pressure and over-temperature, and abnormal sound monitoring, the device can run in a highly safe environment.
- Power adjustment
The variable frequency resonance or non-pulse(optional) continues rotating mode ensures high efficiency and even microwave throughput. It can be set between 0~2000W/0~3000W according to the user’s requirements.
Specifications
| Model | CA-MDS-700-T18 |
| Vessel Quantity | 18 |
| Vessel Volume | 100mL |
| Temperature Monitoring System | Temperature monitoring: Contactless IR sensor
Temperature control: Scanning control of each vessel Temperature control range: 50~400℃; Temperature control accuracy:±0.3℃ |
| Pressure Monitoring System | Contact-less pressure sensor
Pressure control range:0~10MPa Pressure control accuracy:0.01MPa |
| Vessel Material | Inner: imported TFM
Outer: imported PEEK+glass fiber |
| Display | 7-inch touch screen |
| Rotation Mode | 360° Continuous rotation |
| Microwave Power | 0-2000W adjustable/ 0-3000W adjustable |
| Microwave Leak | <5mW/cm² |
| Microwave Frequency | 2450MHz |
| Max. Working Pressure | 6MPa |
| Max. Working Temperature | 250℃ |
| Inner Vessel Temperature Limit | 300℃ |
| Electricity | AC 220V, 16A, 50/60Hz |
| Dimension(L*W*H) | 640*630*590mm |
| N.W./G.W. | 75kg/148kg(Main device+Accessories) |
| Shipping Dimension(L*W*H) | 800*800*810mm (Main device),620*590*560mm (Accessories) |
