Description
General features
- Using unique advanced control technology, equipped with high-quality prisms；
- Greatly improved response speed, measurement time and minimum transmittance；
- 8 inch color dot matrix touch LCD；
- Use light-emitting diodes as light sources to avoid frequent replacement of sodium lamps
- Multi-point automatic calibration；
- Customize up to 300 commonly used measurement methods and pre-store them in the system；
- Adopt silent design；
- Using the latest IT technology, can be networked.
CA-POL-532 features
- Built-in temperature control device with precise heating and cooling(Peltier).
- The temperature control test tube can be used to control the temperature of the sample.
SPECIFICATIONS
| Parameters/Model | CA-POL-532 | CA-POL-531 |
| Measurement mode | Optical rotation, specific rotation, sugar degree and concentration (Custom) | |
| Frequency used methods | 30 | |
| Light source | Light-emitting diode (LED) (up to 10,000 hours) + precision interference filters | |
| Working wavelength | 589.44 nm (Sodium D Spectrum) | |
| Measurement range | ±90° (Optical Rotation) ± 259° Z (Sugar) | |
| Minimum reading | 0.001° | |
| Accuracy | ±0.004° | ±0.006° |
| Repeatability | ≤0.002° | |
| Min. transmission of samples able to be measured | 0.10% | |
| Response speed | 8°/s | |
| Measurement time | 6 Times/26s | |
| Sample temperature control | Yes | No |
| Temperature control mode | Peltier (Built-in) | No |
| Temperature control range | 10-50℃ | No |
| Temperature control accuracy | ±0.2℃ | No |
| Display | 8-inch color dot matrix touch LCD | |
| Calibration method | Multi-point automatic calibration | |
| Data storage | 10000 sets | |
| GMP Regulations | No | |
| Output communication interface | USB/Printer/U disk | |
| Test tubes | 100mm/200mm (regular)
100mm (temp. control) |
100mm/200mm (regular) |
| Optional tubes | 50mm (regular) 200mm (temp. control) |
50mm (regular) |
| Instrument Dimension (W*D*H)(mm) |
702*376*240mm | |
| Package Dimension (W*D*H) (mm) | 880*530*490mm | |
| N.W./G.W.(kg) | 21kg/36kg | |
