Description
- No need for any working medium (no oil), no pollution. The air exchange chamber is equipped with filter materials to ensure air purity.
- Adopt new technology and new materials in the production process. Easy to move and work smoothly, thus ensuring an ideal vacuum degree and a high air flow rate.
- The special electricity motor is provided by the expert motor manufacturer ODM. A reasonable rotation design, equipped with an overheating power-off protector, will automatically power off when the pump body temperature reaches 130°C, and protect the motor from damage during long-term operation.
- Adoptfrictionless film movement, no heat generation, no friction loss. The diaphragm is made of imported rubber, which is corrosion-resistant and has a long service life.
- Automatic cooling and exhaust system, which ensurescontinuous operation for 24 hours.
- The pressure adjustable design can meet the vacuum degree and gas flow rate within a certain range.
- The bearing adopts imported classic bearings, with stable operation, low noise and high working efficiency.
- The parts of the anti-corrosion pump in contact with gas are treated with Teflon surface treatment, which isresistant to chemical corrosion.
- Small size, light weight, easy to move, saving laboratory space, convenient for repair and maintenance.
SPECIFICATIONS
VACP-D31 | |||
Pumping Speed (L/Min) | 20 | Pump Head | 1 |
Ultimate Vacuum | 200mbar | Pump body Temperature (°C) | <55 |
Voltage | 220Vac,50Hz | Dimension(L×W×H) (mm) | 270x130x210 |
Power | 160W | Weight(Kg) | 7 |
Air Inlet (mm) | φ6 | Diaphragm | Imported Rubber |
Air Outlet (mm) | Silencer Cotton | Valve Plate | Imported Rubber |
Operating Ambient Temperature (°C) | 7-40 | Noise(BD) | <60 |
Optional accessory | Retention bottle |
