Description
- Based on the new class B, have 3 pulsating vacuum, vacuum up to -0.9 bar (-0.09 MPa). Residual humidity is <0.2%. Suitable for sterilizing wrap, unwrapping, solid, porous, and hollow devices.
- Use an imported & advanced 16-bit microprocessor, easy to operate. Most suitable for the Dept of Stomatology, Ophthalmology, Surgery, and Lab.
- Equipped with B&D test and vacuum test procedures. To test the penetrability.
- Chamber punched by stainless steel (#304, thickness: 2.5mm), together with the jet type of steam generator, ensures efficient sterilizing.
- With an alarm system for the waste water tank, avoid the waste water entering the sterilizing circulation, and ensure the sterilizing completely.
- Precise LCD display and advanced self-test system ensure you get the working data freely.
- Double lock door system for safety during operating.
- The new design of water tank is on the top, easy to clean.
- Built-in printer
- Optional USB function
- Application: Suitable to sterilizing wrap, unwrap, solid, porous, hollow device. Most suitable for the Dept of Stomatology, Ophthalmology, Surgery and Lab.
SPECIFICATIONS
| Model | STB-B23-3C | STB-B18-3C |
| Sterilization level | CLASS B (European Class B) | |
| Sterilization temperature | 134℃/121℃ | |
| Display accuracy | ±0.5℃ | |
| Recording accuracy | ±0.5℃ | |
| Sensor accuracy | 0.01℃ | |
| Special sterilization | Kill active HV,HBV,BSE and spore | |
| Drying program | Strong vacuum drying, the residual humidity<0.2% | |
| Display | Widescreen LCD display | |
| Test | Bowie & Dick steam penetration test,Vacuum test,Helix spiral test | |
| Safety | Safety valve, pressure lock, fault self-check | |
| Sterilization record | Built-in Printer and optional USB to record the sterilization process and date | |
| Water supply system | 6.5L distiller water tank,3L waste water tank | |
| Cleaning program | Automatic clean inside pipe and steam generator | |
| Sterilization configuration | 5 layers, 3 trays (circular shape, more space in actual use) | |
| Power | 2000 W | 1800 W |
| Voltage | AC220V/110V±10% | |
| Frequency | 50/60Hz±1Hz | |
| Tank Capacity | 23 Litres | 18 Litres |
| Appearance Size (mm) | 480×630×420 | 480×560×420 |
| Inside Dimension (mm) | Φ249×450 | Φ249×355 |
| Package Dimension (mm) | 750×595×525 | 675×595×525 |
| G·W | 50 kg | 47 kg |
