Description
- Based on the new class B, have 3 pulsating vacuum, vacuum up to -90kPa (-0.09MPa). Residual humidity is <0.2. Suitable for sterilizing wrap, unwrapping, solid, porous, and hollow devices.
- Use an imported & advanced 16-bit microprocessor, easy to operate. Suitable for the Dept of Stomatology, Ophthalmology, Surgery, and Lab.
- Equipped with B&D test and vacuum test procedures. To test the penetrability.
- Chamber punched by Stainless Steel (#304, thickness: 2.5mm), together with the jet type of steam generator, ensures efficient sterilizing.
- With an alarm system for the waste water tank, it avoids the waste water entering the sterilizing circulation and ensures the sterilization completely.
- Precise LCD display and advanced self-test system ensure you get the working data freely.
- Double lock door system for safety during operation.
- Built-in printer
- Optional USB function
Application:
Suitable to sterilizing wrap, unwrap, solid, porous, hollow device. Suitable for the Dept of Stomatology, Ophthalmology, Surgery and Lab.
Specifications
Model classification
| Model | Power | Voltage | Frequency | Tank Capacity | Appearance size (mm) | Inside Dimension (mm) | Package Dimension (mm) | G·W |
| STB-B23-2B | 2000 W | AC220V/110V | 50/60Hz | 23Litres | 445×640×395 | Φ249×450 | 740×550×500 | 53 kg |
| STB-B18-2B | 1800 W | AC220V/110V | 50/60Hz | 18Litres | 445×550×395 | Φ249×355 | 670×550×500 | 48 kg |
| STB-B16-2B | 1800 W | AC220V/110V | 50/60Hz | 16Litres | 445×550×395 | Φ230×360 | 670×550×500 | 47 kg |
| STB-B12-2B | 1800 W | AC220V/110V | 50/60Hz | 12Litres | 445×550×395 | Φ200×360 | 670×550×500 | 46 kg |
Technical parameter
| Sterilization level | CLASS B (European Class B) |
| Sterilization temperature | 134℃/121℃ |
| Display accuracy | ±0.5℃ |
| Recording accuracy | ±0.5℃ |
| Sensor accuracy | 0.01℃ |
| Special sterilization | Kill active HV,HBV,BSE and spore |
| Drying program | Strong vacuum drying,the residual humidity<0.2% |
| Display | Widescreen LCD display |
| Test | Bowie & Dick steam penetration test, Vacuum test, Helix spiral test |
| Safety | Safety valve, pressure lock, fault self-check |
| Sterilization record | Optional USB, printer (built-in or external) to record the sterilization process and date |
| Water supply system | 3L distiller water tank,3L waste water tank |
| Cleaning program | Automatic clean inside pipe and steam generator |
| Sterilization configuration | 5 layers, 3 trays (circular shape, more space in actual use) |
