Description
- APS-coated, sturdy housing with high resistance to corrosion
- 20 editable programs can be stored in the system
- Integrated high-quality LCD screen with intuitive bilingual (Chinese/English) software
- Fully intelligent design enables timely determination and automatic recovery from an abnormal event
- Real-time visual simulation with icons displays the working status dynamically
- Green inner-cycling air purification system to efficiently adsorb, remove poisonous gas; gas-effluxion mechanism, environmentally friendly and safe
- This system can be automatically started at any time as programmed
- Manual adjustment can be conducted anytime during the programmed automatic operation; afterwards, the system automatically enters the programmed operation
- Automated fan control: Stays on all the time when the specimens are not submerged in the cup, and comes on for 10 seconds every minute when the specimens are submerged in the cup and in processing
- Automated light control: stays on all the time during programming, stays off during the automatic operation and can be automatically turned on anytime by touching the screen or any key and stays for 2 minutes.
- Internal dry heating mechanism with high-precision temperature control
- Low-energy-consuming control circuit with power protection function. When a power outage occurs, the screen displays as normal with a scrolling bar demonstrating the on status of the power protection system.
- Battery backup with more than 30 hours of running power
- Approximately 100 tissue specimens can be dehydrated at the same time
Specifications
| Number of Cups | 12 (9 for reagents, and the cups at the 10th, 11th, and 12th stations are used for paraffin melting) |
| Capacity of Each Cup | 1500ml |
| Length of Processing Time in the Cup | Any length for the first cup (Extended Time), any length between 0 and 24 hours for the other cups |
| Temperature Range | RT – 80℃ |
| Dripping Time | Adjustable within 10-60 s; shake/drip above cup |
| Frequency of Agitation | Adjustable within 0-6 times/minute |
| Tissue Protection Station | any station from the 1st to 7th station as preset |
| Working Voltage | AC220V±10% 50Hz (standard model); AC110V±10% 60Hz |
| Power | 500 W |
| Dimensions | 1055×480×495 mm (W×D×H) |
| Net weight | 75 kg |
