Blood Bank Refrigerators store and protect refrigerated whole blood, blood components, and blood products by maintaining a uniform temperature. Purpose of Blood Bank refrigerator Professional Blood Bank refrigerators store blood, as well as medicines and bioproducts. Suitable for blood banks, hospitals, and CDCs.
Reliability and Key Features Microprocessor-controlled forced-air cooling with an electrical heat compensation system. Digital temperature display for upper and low sections in the chamber with 0.1℃ resolution. Consistent cabinet temperature 2-6℃. High-tech integrated sensors to display and control temperature. Auto-defrost to remove moisture on the cooling surface. Large digital display for easy observation.
Safety of Blood Bank Refrigerators Build-in backup battery to display temperature and to operate audible and visual alarm systems for up to 72 hours without ac power. Equipped with a complete temperature alarm system featuring an audible buzzer and visible flashing light. Five alarm conditions: High/low temperature, power failure, voltage abnormal, door ajar, backup battery. Standard with thermal printer. Standard with an acrylic inner small door, for less affection on other room when one door open.
Ergonomic Design of Blood Bank Refrigerators Safety lock to prevent unauthorized access. Storage space designed for easy sorting of various blood products. Caster design and interior light.
Specifications
Model
BR4-660
BR4-1000
Specifications
Shelf/drawer
Shelves/12
Drawers/12
Cooling
Forced -air Cooling
Forced -air Cooling
Defrost
Auto
Auto
Refrigerant
R134a
R134a
Power consumption(kWh/24h)
6.31
8.53
Noise(db)
51.2 dB(A)
53.6 dB(A)
Ambient temperature(℃）
10~32℃
10~32℃
Temperature range(℃）
4±1℃
4±1℃
Cooling system
Compressor brand/QTY
SECOP/1
SECOP/1
Sensor
NTC
NTC
Temperature controller
Microprocessor
Microprocessor
Display
Digital display
Digital display
Power
Voltage/frequency(V/Hz)
220/50Hz
220/50Hz
Power(W)
364W
513W
Current(A)
2.42A
2.37A
Material
Inside material
304 Stainless steel
304 Stainless steel
Outside material
Color sprayed steel
Color sprayed steel
Insulation
PURF
PURF
Size
Capacity(L/cu.ft)
658/23.23
1008/35.59
Bloodbags(450ml)
360
576
NW./GW.（kg)
202/257
265/335
Exterior size(W×D×H)(mm)
1220×640×1885
1240×860×1895
Interior size(W×D×H)(mm)
1100×454×1325
1100×684×1325
Package size(W×D×H)(mm)
1330×740×2120
1325×970×2130
CBM
2.09
2.74
20GP/40GP/40HQ
12/27/27
8/18/18
Alarm
High/low temperature
Y
Y
Power off
Y
Y
Temperature controller malfunction
Y
Y
Backup battery malfunction
Y
Y
Ambient temperature
10~32℃
10~32℃
Power failure backup system(alarm)
72h
72h
Accessories
Caster
Y
Y
Outer door/Type
2/Heating & Foam glass door
2/Heating & Foam glass door
Inner door
6
6
Test hole
1/25MM
1/25MM
Thermal printer
Y
Y
Light
LED
LED
Temperature recorder
Optional chart recorder
Optional chart recorder
