Description
- High-precision, low-noise, and wear-resistant photoelectric positioning system
- Two sets of operation mechanisms double the processing capacity. An optional single-mechanism mode for processing a small number of tissue specimens, easing the operation
- The scrolling processing mode multiplies the processing capacity of the system. A processed basket can be continuously used following another basket that is in processing without interruption, thus achieving a continuous cycling operation
- 20 editable programs for each of the A and B mechanisms can be stored in the system
- Integrated high-quality, colored super-large LCD touch-screen
- Fully intelligent design, enabling timely determination and automatic recovery from an abnormal event
- Real-time visual simulation with icons displays working status dynamically, clearly and intuitively
- Green inner-cycling air purification system
- This system can be automatically started at any time as programmed (Setting Range 0-99 hours and 0-59 minutes)
- Power Protection Station: Station 7 for A basket and Station 5 for B basket, ensuring continued operation during a power outage.
- Automated fan and light control
- Internal dry heating mechanism and triple protection channels offer high-precision automatic gradient temperature control
- Low-energy-consuming control circuit with power protection function. Battery backup with more than 30 hours of running power
- Manual operation can be conducted anytime during the programmed automatic operation, allowing the user to check or add tissue specimens during the operation
- 250 or more specimens can be processed at the same time
Specifications
| Number of Cups | 14(10 for reagents, and the cups at the 11th, 12th, 13th, and 14thstations are used for paraffin melting) |
| Baskets | 2 baskets. The Dehydration basket is divided into three layers to ease the categorisation of tissue. |
| Capacity of Each Cup | 2000 ml |
| Temperature range | RT – 80℃ |
| Temperature Control Precision | ±1℃ |
| Length of Processing Time in the Cup | Any length between 0 and 99 hours for the 1st and 2nd cup, any length between 0 and 24 hours for the 3rd to 14th cup |
| Dripping Time | Adjustable within 10s – 60s; shake/drip above cup |
| Frequency of Agitation | 0 – 6 times/min adjustable |
| Working Voltage | AC 220V±10% 50Hz (standard model); AC110V±10% 60Hz |
| Power | 550 W |
| Dimensions | 1370×440×525 mm (W×D×H) |
| Weight | 102 kg |
| Package Dimension (W*D*H) | 1520*610*770mm |
| G.W.(kg) | 155Kg |
