Description
Key Features of Biomedical Freezer
1.Upright side door with build-in handle for easy-opening; limit door hinge to prevent collision when door open.
2.Lockable caster design for customer to move as needed.
3.Wide voltage tolerance design with applicable voltage range of 187~242V/AC.
Safety
1.Multiple malfunction alarms including high and low temperature, sensor error, power off, temperature controller malfunction, door ajar.
2.Two types of alarm indications: audible buzzing and visible flashing light.
3.Power failure protect: the device would be attack by the high current when all devices restart simultaneously, the start-delay function would protect device from damage.
4.Controller password protect function to avoid change running parameter randomly.
Reliability
1.Chemically stable, CFC-free, commercially available and environmentally, safe refrigerant.
2.High density CFC-free urethane foam insulation for rigidity and stable storage temperature.
3.Microprocessor control, digital display adjustable temperature range: -10℃~-25℃.
4.LED digital display for clear observation.
Specifications
| Model | LF25-360 | |
| Specifications | Shelf (drawer) | Shelves/4 drawers/12 |
| Cooling method | Direct cooling | |
| Defrost | Manual | |
| Refrigerant | R290 | |
| Power consumption (kWh/24h) | 3.2 | |
| Noise（db) | 49 | |
| Ambient temperature（℃） | 10~32℃ | |
| Temperature range（℃） | ·-10~25℃ | |
| Cooling system | Compressor brand/QTY | CUBIGEL/2 |
| Sensor | NTC | |
| Temperature controller | Microprocessor | |
| Display | Digital display | |
| Power | Voltage/frequency(V/Hz) | 220/50Hz |
| Power(W) | 310W | |
| Current(A) | 3A | |
| Material | Inside material | Color sprayed steel |
| Outside material | Color sprayed steel | |
| Insulation | PURF | |
| Size | Capacity(L/cu.ft) | 358/12.6 |
| NW./GW.(kg) | 138/178 | |
| Exterior size(W×D×H)(mm) | 673×676×1620 | |
| Interior size(W×D×H)(mm) | 466×636×625 | |
| Package size(W×D×H)(mm) | 780×920×1990 | |
| CBM | 1.43 | |
| 20GP/40GP/40HQ | 18/39/39 | |
| Alarm | High/low temperature | Y |
| Power off | Y | |
| Sensor malfunction | Y | |
| Ambient temperature（℃） | Y | |
| Abnormal voltage | / | |
| Temperature controller malfunction | Y | |
| Door ajar | Y | |
| Power failure backup system(alarm) | 8H | |
| Accessories | Caster | Y |
| Test hole | 2/25MM | |
| USB port | Y | |
| Data logger | Optional | |
| Remote alarm | Optional |
